NA62/NA82
Home Products Ceiling Speakers > NA62/NA82
Technical Parameter
| Model | NA62 | NA82 |
| Woofer | 6-1/2" polypropylene or kevlar | 8" polypropylene or kevlar |
| Tweeter | 1" ferrofluid cooled silk dome±3dB treble switch | 1" ferrofluid cooled silk dome±3dB treble switch |
| Power handling | 100Watts | 150Watts |
| Frequency response | 50-20,000Hz | 30-20,000Hz |
| Sensitivity | 88dB@1W/1M | 88dB@1W/1M |
| Impedance | 8 Ohms | 8 Ohms |
| Line voltage | 70/100V | 70/100V |
| Dimension(DiaxD) | 223x91mm/8-3/4"x3-1/2" | 279x120mm/11"x4-3/4" |
| Cutout size(Dia) | 203mm/8" | 245mm/9-5/8" |
| Mounting depth | 89mm/3-1/2" | 117mm/4-5/8" |
